Machine installation
CHARACTERISTICS
Fully encased model to provide operator safety, sound insulation and the possibility
of working with large quantities of liquid
n
HSSdiskø370x32x3forsteel n
HM disk ø 400 x 32 x 3.6 for aluminium and light alloys n
Cabinet for electric and electronic equipment with fully identifiable wiring, door---
locking switch with padlockable device, emergency device, motor overload cut---out,
minimum voltage coil and protection against a missing phase
n
Activation and control systems protected by input and output electric and elec-
tronic devices
n
Low tension control panel: softkey polyester keypad with thermo---moulded touch
sensitive buttons and acoustic signal when the machine is started
n
48 character x 16 line display showing technical pa rameters such as: number of cuts
programmed and executed, blade thickness, single forward movement measure,
cutting time, ammeter, display of diagnostic messages (approx. 80) and warnings in
the language chosen
n
Four controls to program the cutt ing head st roke limits, according to the dimen-
sions of the bars to be cut
n
Programming and control console wit h LCD display comprehensive of self---diag-
nosis messages
n
Blade rotation with motor at a speed, together with an electronic variable speed
drive, making cutting possible from 15 to 150 rpm to always accomplish the best
efficiency
n
Spray gun to wash the work surfaces n
Pneumatic clamp with adjustable steel gib n
Acoustic and flashing light signal in case of machine stop n
Infeed unit with step motor; screw/nut with ball bushing (length 1000 mm) n
Vice with rag prevention device and double workpiece clamping feature n
Swing feeder vice to deliver even deformed bars n
Coolant tank obtained in the pedestal with a pair of motor pumps for a total deliv-
ery of 120 l/min
n
Chip drawer n
Electric pump to lubricate and cool the disk n
Blade cleaning brush n
Upright pneumatic vice for cutting more than one bar n
Cutting head moving on twin linear guide wi th pre---loaded double ball---bushing
sliding blocks
n
Head movement with electro---mechanical cylinder to provide the greatest cutting
rigidity
n
Rotating pin with pre---loaded thrust bearing to ensure precision and reliability n
Machine set for handling with pallet truck n
Keys, user manual and manual for ordering spare parts in the language used n
Motor chip discharger n
Roller platform adapter on loading and unloading side n
Emulsifiable oil 5 l n
MEP slide bar loader for high production (CB6001)* n
*A CCESSORIES AVAILABLE ON REQUEST
A ccessory kit is placed before the packaging inside the machine; it contains the
following items:
H 3, 4, 5, 6, 8 and 10 mm Allen keys;
H open 19 mm wrench;
