Tigo TS4-A - TAP Placement Example - Mesh

TAP PLACEMENT EXAMPLE - MESH
13
33ft (10m) max
230ft (70m) max
33ft (10m) max
Place TAP within 10m of any TS4 unit in the array.
Maximum distance of 10m between TS4 units that belong to a single TAP.
Maximum distance of 35m (115ft) between TAP and farthest TS4 unit.
Connect multiple TAPs in series for larger arrays.
accesspoint
