Timan 3330 - 9 Technical Data

TECHNICAL DATA
26
9. TECHNICAL DATA
Model
TIMAN 3330
Motor
Kubota
Number of cylinders
3
Piston displacement
962
Hp/kW
33/24
Cooling system
Water cooling (45°C outdoor temperature)
Gasoline tank
37 L
Transmission
Piston pumps
Wheel motors
4x Orbital motors
Speed
0-27 km/h
Work hydraulics
Gear pumps
Capacity outlet rear
48 L/min (nominal) 180 Bar
Capacity outlet front
48 L/min (nominal) 180 Bar
Oil outlet in front
1 double-acting with flowing position 150
Oil outlet rear
1 double-acting 150 Bar
Lifting arm
Flow position and parallel lift standing
Lifting capacity
150 kg 80 cm from quick connector
300kg close to quick connector
Sound level cabin EU1322/2014 method B
79dB
Driving noise EU985/2018 running
71dB
Driving noise EU985/2018 standing
74dB
Source strength L
wa
ISO 6395:2008
105dB
Electrical system
12 volt
Generator
65 amp
Driving work lights front
2 + 2 pcs
Rear working light
1 pcs
Rotating beacon
standard
13 pole trailer connector
standard
Radio with CD, BT and hands-free
Standard
Weights and Measures
Access height
500 mm
Length
2700 mm
Width
1130 mm
Height
1990 mm
Turning radius (internal)
530 mm
Net weight
1060 kg
Movable weight
1185 kg
