STEERING COLUMN, OPERATOR'S GRIP, CABINET AND AIR SWITCHES.
13
5.2 Display
1. Hydraulic oil level. Warning, and low-level acoustic alarm.
2. Charging indicator.
3. Engine Warning Light. Engine fault. Error codes appear on the information display.
4. Engine oil pressure. Warning if oil pressure is too low, and an acoustic alarm.
5. Differential lock activated (not available on Timan 3330).
6. Hydraulic oil temperature. Warning if the hydraulic oil temperature gets too high.
7. Parking brake activated.
8. Rotating beacon activated.
9. Hazard lights enabled.
10. Low beam activated.
11. High beam activated.
12. Trailer indicator light activated.
13. Fuel level warning, at low level.
14. Fuel level indicator.
15. Left indicator.
16. Right indicator.
17. Engine water temperature indicator.
18. Engine water temperature warning in the event
of high temperature.
19. Digital display.
20. Driving speed.
21. Revolutions per minute.
22. Set points for cruise control.
23. Timer.
24. Drive mode - ROAD or WORK mode - toggles between modes with hand throttle
potentiometer.
25. Driving direction. F = Forward, R = Reverse.
