Timberwolf TPS35 - Minimum Mantel Clearances; Alcove Installation Requirements (Minimum)

W415-0865 / B / 05.26.11
24
5.4 MINIMUM MANTEL CLEARANCES
!
WARNING
RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE
TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO
OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE
CLEARLY MAINTAINED.
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
73.1
8”
14”
12”
10”
10”
16” MANTEL
14”
12”
30”
48”
35”
STOVE
Minimum Alcove Dimensions
5.5 ALCOVE INSTALLATION REQUIREMENTS (MINIMUM)
