W415-0865 / B / 05.26.11
39
11.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMMON COMPONENTS
REF PART NO. DESCRIPTION
1 W660-0052 LOW LIMIT SWITCH 140°F (60°C)
2 W660-0055 HIGH LIMIT SWITCH 200°F (93°C)
3 W660-0056 VACUUM SWITCH
4 W325-0043 HANDLE, SPRING
5* W195-0004 POWER CORD
6 W435-0019 AUGER MOTOR
7 W062-0025 CONVECTION BLOWER (TPS35)
7 W062-0030 CONVECTION BLOWER (TPI35)
8 W062-0027 COMBUSTION BLOWER
9 W290-0111 COMBUSTION BLOWER MOUNTING GASKET
10 W290-0120 COMBUSTION BLOWER MOTOR MOUNTING GASKET
11 W290-0113 CONVECTION BLOWER GASKET
12 W570-0107 AUGER SCREW
13 W190-0035 CONTROL
14 W105-0012 NYLON BUSHING
15 W500-0501 AUGER RETAINER C/W SCREW
16 W555-0061 SCRAPER ROD
17* W750-0227 HARNESS WIRE
18* W385-0487 TIMBERWOLF® LOGO
19* W562-0004 GLASS GASKET (3/4" CHANNEL)
20 W720-0139 EXHAUST TUBE
21 W357-0007 IGNITOR
22
W135-0320 CAST, BURN POT
23
W290-0119 IGNITION GASKET
24*
W460-0004 RECEPTACLE
25
W300-0131 GLASS
26*
W562-0010 DOOR GASKET (3/8" ROPE)
27*
W660-0083 SWITCH, HOPPER
28
W715-0843 DECORATIVE INSET
29
W225-0258 DOOR, BLACK
30* W430-0013 DOOR MAGNET ASSEMBLY
31 W325-0018 DOOR HANDLE
32 W320-0002 DOOR HANDLE LATCH
33* W285-0002 FUSE, 2 AMP
