6. Configuration
Note: If no key is pressed for approximately 60 seconds, the controller will
automatically reset back to the first user-interface screen (see Figure 8).
6.1 Pump Configuration
Note: all relays (pump outputs) will be disabled while in the pump
configuration menu and will not be re-enabled until the last option has been
set and EXIT is pressed. If no key is pressed for approximately 60 seconds,
the controller will automatically revert to the run mode screen (Figure 8) and
re-enable the relay outputs.
1) Press CFG once; the screen will change to the CONFIG screen
2) On the CONFIG screen the selections are
• Pump Config
• System Config
• Display Options
• Communications
3) Press Selct when the selection arrows are pointing to the “Pump Config” option
4) A confirmation screen will appear: “STOP SYSTEM”
5) Press Exit to cancel and return to the CONFIG screen
6) Press OK to advance into the pump configuration menu
7) The PUMP Configuration screen presents the following
• DOWN
• UP
• Select Num Pumps x
8) Use the ↑ or ↓ keys to select the setting you would like and press Selct (the
currently selected option will be displayed in reverse video e.g.: DOWN)
9) Press Selct when the selection arrows are pointing to “Select Num Pumps” to
adjust the number of pumps to be controlled (1 to 3)
10) Use the + and – keys to adjust the number of pumps
11) Press Enter to lock in the value
12) Press Next to continue to input type
13) The input type presents three choices:
• FLOAT
• 4-20 mA
• 4-20 mA → FLOAT
•
• Alarm Float: OFF/ON
• Activate Pumps x
To Next Page
