6.2.3 Reset Run Times
1) Press ↓ until the selection arrows are pointing to the “Reset Run Times” option
and then press Selct
2) The following choices will be presented:
• P1 xxxx.x
• P2 xxxx.x
• P3 xxxx.x
3) Use the ↑ or ↓ keys to select the pump run time to be reset and press Selct
4) Press OK to clear the run time to 0.0 hours
5) Press Exit to cancel
6) Press Exit again to return to the CONFIG – SYSTEM menu
7) Keep pressing Exit to return to the normal run mode screen (Figure 8)
6.2.4 Version Number
Note: This menu has no user settings, it is provided only for troubleshooting
purposes to provide information to technical support when/if required. This allows
the tracking of the current version of the firmware in the controller.
The firmware in the controller may be updated in the field to add functionality
or fix issues identified after manufacture. Consult with a Time Mark
representative for more information.
1) Press ↓ until the selection arrows are pointing to “Version Number” and then
press Selct
2) The following options will be displayed
• Build date dd-mmm-yy
• Build time hh:mm:ss
3) Press Exit again to return to the CONFIG – SYSTEM menu
4) Keep pressing Exit to return to the normal run mode screen (Figure 8)
6.2.5 Clear Log
1) Press ↓ until the selection arrows are pointing to “Clear Log” and then press
Selct
2) A confirmation screen will appear “CLEAR LOGS”
3) Press EXIT to cancel and return to the previous screen
4) Press OK to clear all the log information from the controller.
5) Keep pressing Exit to return to the normal run mode screen (Figure 8)
6.3 Display Options
The display options menu will allow you to adjust the backlight and contrast of the
display to allow for more readable options. Use the ↑ and ↓ keys to select and
adjust the values if necessary, being sure to press Enter to lock in the values.
