Page 23 of 41
Rev: 2024-10-03
5) Press Selct when the arrows are pointing to “SPAN”
6) The output should switch to 20 mA, use the +1 and -1 buttons to adjust each
digit, pressing the left arrow key (←) to move between the digits. Adjust this
value until the multimeter is reading 20.00 mA
7) Press ENTER to lock in this value
8) Press Exit to leave calibration mode and enter normal operation
It is good practice to reboot the controller after calibration, though this may not be
strictly necessary.
6.6 Status Screen
Press Stat to see the System Status screen
The SYSTEM STATUS screen shows the following:
• P1 H O A [ERR] xxxx.x
• P2 H O A [ERR] xxxx.x
• P3 H O A [ERR] xxxx.x
This screen shows the status of the pump outputs. The number of pumps shown will
depend on the number of pumps selected in the PUMP configuration. [ERR] will
either be OFF, ON, or ERR. If ERR is shown, a contact failure alarm has occurred,
and the HOA status should be OFF. The value displayed to the far right is the run
time for the pump in hours, updated in tenths of hours (every 6 minutes).
1) Press HOA to enter the PUMP HOA menu
2) Use the ↓ or ↑ keys to select which pump you want to control
3) Use the → or ← keys to select H, O, or A (H = HAND, or forced ON, O =
OFF, or forced OFF, and A = Auto)
Note: the HOA status should change as soon as you press the arrow keys.
4) Press Enter to exit HOA mode
5) Repeat these steps for the other pumps, if necessary
6.7 Alarm Screen
If the word “ALARM” is showing on the main run screen (Figure 8) press Alrm to see
the status of the alarms:
• P1 Alrms: SF OT CF SP
• P2 Alrms: SF OT CF SP
• P3 Alrms: SF OT CF SP
• Level Alarm
• Improper Sequence Alarm
