9.3 Discrete Inputs
• Read: 0x02
• Write: NONE; read only registers
• Format: 1xxxx
Address
Description
Notes
0
Pump 1 bits 4-1
Lower Nibble (4-bits)
Pump 2 bits 8-5
Upper Nibble (4-bits)
1
Pump 1 Spare
Bit 0
Pump 1 Contactor
Bit 1
Pump 1 Over Temp
Bit 2
Pump 1 Seal Fail
Bit 3
Pump 2 Spare
Bit 4
Pump 2 Contactor
Bit 5
Pump 2 Over Temp
Bit 6
Pump 2 Seal Fail
Bit 7
2
Pump 3 bits 4-1
Lower Nibble (4-bits)
Bits 8-5 unused
Upper Nibble (4-bits)
3
Pump 3 Spare
Bit 0
Pump 3 Contactor
Bit 1
Pump 3 Over Temp
Bit 2
Pump 3 Seal Fail
Bit 3
