SPECIFICATIONS
EMBEDDING CRYO
MODULE MODULE
Ambient Operating 10° – 40° C 10° – 40° C
Temperature and
Relative Humidity Range 30% – 85% RH, 30% – 85% RH
(noncondensing) (noncondensing)
Dimensions/Weight Width 57.5 cm (22.6 in) Width 33.0 cm (13.0 in)
Depth 64.2 cm (25.3 in) Depth 61.7 cm (24.3 in)
Height 37.7 cm (14.8 in) Height 37.7 cm (14.8 in)
Weight approx. 26 kgs (57 lbs) Weight approx. 22 kgs (48 lbs)
Power Required Model No. 5238: 100 VAC ±10% or less,
100 VAC ±10% or less, @ 2.0 amps 50/60 Hz
@ 9.0 amps 50/60 Hz
Model Nos. 5100, 5235: 115 VAC ±10% or less,
115 VAC ±10% or less, @ 2.0 amps 60 Hz
@ 9.0 amps 60 Hz
Model Nos. 5229, 5232: 220 – 240 VAC ±10% or
220 – 240 VAC ±10% or less, @ 2.0 amps 50 Hz
less, @ 9.0 amps 50 Hz
Chamber Capacity Paraffin Chamber:
approx. 4 liters (no chambers)
Left and Right Chambers:
approx. 1.5 liters
Temperature Range Paraffin Chamber, Right and Cooling Plate:
Available Left Chambers, Hot Plate: –10°C to 0°C
50°C – 75°C
Electric Forceps(optional):1 to 5
Factory Set Temperature Paraffin Chamber, Left and Cooling Plate:
Right Chambers, Hot Plate: – 5°C
62°C
Cold Spot: approx. 15°C at
25°C room temp. and
40% R.H.
Electric Forceps(optional): 3
Circuit Breaker/ON-OFF 15 amps
Switch
Memory Backup Long-life battery
Safety Standards Tested and listed by Intertek Testing Services (ITS)
Complies with: UL 3101-1, 1st ed., IEC 1010-1 and
CAN/CSA-C22.2 No. 1010.1-92
