9
USB-2CAN-SI-M
Number of Ports
Two
Connector
DB9 male connector
5-pin terminal block
CAN Bus Speed
20kbits to 1Mbits for CAN data transmit & receive
Signals
CAN_H, CAN_L, CAN_GND, CAN_V+
CAN Bus Controller
Bosch C_CAN module
LED
CAN bus data activity, CAN bus error
CAN Bus Mode
Standard mode: normal operation on CAN bus
Listen mode: passive receiving of CAN frames
Echo m
ode: transmitter also receives sent frames (for
testing purposes)
Protection
+/-16 KV ESD protection for CAN signals
2500V galvanic isolation on CAN bus
Software Features
API Library
Supports C/C++, C#, VB.NET and LabVIEW
Utility
On-board firmware update utility
OS Driver Support
Windows XP to Windows 10 OS
Windows Server 2003 to 2012 R2
Monitoring Tools
Supported by CANHacker, Titan CAN test program
Power Requirement
Power Input
Power supplied via USB (5V) connector
No external power needed
Power Consumption
Max. 300mA@5VDC (USB-2CAN-M)
Max. 500mA@5VDC (USB-2CAN-SI-M)
Mechanical
Casing
SECC sheet metal (1mm)
Dimensions
115 mm x 85 mm x 28 mm (L x W x H)
Weight
310g
