Titan Electronics USB-2CAN-M - ASCII Commands

18
8.2 ASCII Command Set
The USB CAN adapter can be registered as a virtual serial port on the host computer.
With simple ASCII commands the USB CAN adapter can be controlled over this serial
port. User can send/receive commands from any simple serial terminal program.
Example: Set bitrate to 500Kbps, open CAN channel, send CAN frame (ID = 002h, DLC
= 3, Data = 11 22 33), close CAN:
Command
Response
Function
S6[CR]
[CR]
Set bitrate of USB CAN adapter to 500Kbps
O[CR]
[CR]
Open CAN channel
t0023112233[CR]
z[CR]
Send CAN message (ID = 002h, DLC = 3, Data = 11
22 33)
C[CR]
[CR]
Close CAN channel
