Titan Electronics USB-2CAN-M - Setting CAN Bitrate (Standard)

21
8.3.3 Setting CAN Bitrate (Standard)
The CAN bus bitrate can be set with the command SX[CR]. The command can only be
used if the CAN bus channel is closed.
Command
Response
Function
S00[CR]
[CR]
Set the CAN bus bitrate to 5K
S0[CR]
[CR]
Set the CAN bus bitrate to 10K
S1[CR]
[CR]
Set the CAN bus bitrate to 20K
S2[CR]
[CR]
Set the CAN bus bitrate to 50K
S3[CR]
[CR]
Set the CAN bus bitrate to 100K
S4[CR]
[CR]
Set the CAN bus bitrate to 125K
S5[CR]
[CR]
Set the CAN bus bitrate to 250K
S6[CR]
[CR]
Set the CAN bus bitrate to 500K
S7[CR]
[CR]
Set the CAN bus bitrate to 800K
S8[CR]
[CR]
Set the CAN bus bitrate to 1M
Example: S6[CR] will be set USB CAN adapter to 500K bps CAN Bitrates.
Note: The USB-CAN-SI-M only supports 20 K bits to 1 M bits.
