TKS 6150 - 6 Control System

Tks Operator’s manual
37
6 Control system
4
2
1
Multi cable solution
21 * 0,75 mm²
TKS connection-box
OUTPUT INPUT
Power supply
12V DC
COBO Connector
3-pin
3
1. Lift UP
2. Lift DOWN
3. Tip UP
4. Tip DWN
1
6
1
5
8
1
7
1
21
1
23 25
1
2722 24
26
28
5. Table FST
6. Table SLW
7. Tab le REV
8. Beacon
21. IR
22. Load ARM (2,6m)
23. Tab le LOAD (2,2m)
24. Table UNLOAD (2,1m)
25. Tip UP (1,8m)
26. Filmbreak (3m)
27. Ext STOP (3m)
28.
Emergency STOP
Hydraulic valve cables with
Hirschmann connectors
40
40. Connection to monitor (5m)
1093 DLS
Cable length:
2,5 meter
Cable length:
5 meter
Cable length: 0,7 meter
ESC
ESC
ENTER
ENTER
STOP
START
TKS Complete Bale Wrap Control System 014-2-0100
Monitor 014-2-0100
TKS Bale Wrap Control Box 014-2-0120
Inductive sensor M12 npn 110-1-5004
Emergency stop 051-3-0004
