Tks Operator’s manual
9
Technical specifi cations
Trailed bale wrapper 6150
Weight machine 1505 Kg
Weight machine with counterweights 1825 Kg
Oil fl ow requirements Approx. 35 l/min (150bar)
Power supply 12V
Maximum turn table speed Approx. 30 rpm
Drawbar Std
Film pre-stretcher, standard width 750mm
Nominel fi lm pre-stretch 60 %
Number of fi lm layers 2+2+.....
Operation
Control system Electronic control system
Control panel Boks med display og joystick
Bale size
Round bale diameter 1,0 - 1,6 m
Bale length Max. 1,2 m
Bale weight on:
Standard machine 800 Kg
Machine with counter weight on hub 1000 Kg
Machine with counter weight on frame 1200 Kg
Machine w/ counter weight on hub and frame Max.1400 Kg
Wheel dimensions
Alt 1 300/80-15.3”
Alt 2 400/60-15.5”
Alt 3 500/45-17”
Available equipment
2 fi lm holders (5+2)
Road lights and road light brackets
Counter weight 230 Kg - mounted on frame
Counter weight 90 Kg - mounted on hub
Alternative pre-stretch 55% or 65%
