Tks Operator’s manual
43
Diameter
Material 8.8 Material 8.8
M5 5.7 Nm 50,5 lb.in
M6 9.9 Nm 7.3 lb.ft
M8 24 Nm 17.7 lb.ft
M10 48 Nm 35.4 lb.ft
M12 85 Nm 62.7 lb.ft
M16 210 Nm 155 lb.ft
M20 400 Nm 295 lb.ft
M24 1000 Nm 737 lb.ft
Lubricate the machine in accordance with lubrication chart. See Fig. 41
• Check that all nuts and bolts have been properly tightened
• Check all functions
Re-tensioning bolts
Check thoroughly all bolts of drawbar, top section’s hinge pins, wheels and wheel shafts after 1
hour of use and thereafter weekly. All other bolts and nuts should be checked after 8 hours of use
and thereafter weekly.
Recommended bolt tensioning torque:
