Compact IP Codec User's Manual
9
T
echno Mathematical Co.
, Ltd.
2140P
streams.
(7) Remote connection
port
This Ethernet port connects to the setu
p PC.
(8) Reset button
This button resets the Product to resta
rt when an error is
generated, etc.
(9) HDMI input port
Inputs HDMI signals. (TM7006E)
(10) HD-SDI input port
Inputs HD-SDI signals. (TM7007E
)
(1
1) HDMI output port
Outputs HDMI signals. (TM7006D)
(12)
A
USB port and HDMI port (disa
bled) is located under the cover
. (TM7006E/7E)
(13)
A
USB port is located under the cove
r
. (TM7006D)
(1) to (8) are common to all three m
odels, while (9) through (13) are unique t
o each model.
