Compact IP Codec User's Manual
10
Techno Mathematical Co., Ltd.
2140P
3.
Operation
Operation Flow
The flow of basic operations is shown below.
*The first time the device is used or whenever network settings (device IP
address, etc.) are changed, configure 4. Basic Settings after (2).
(1) Connect the device and camera, monitor, router, and other peripherals.
(5. Connecting the Encoder or Decoder)
(2) Turn on the device and peripherals.
(3.2 Turning Power ON or OFF)
(3) Connect a PC to the device, and
perform operations and configure
settings on the PC using the
application.
(3.3 Controlling the Device from a PC)
(4) Perform operations and configure
settings from the device preset
switches.
(3.4 Controlling the Device with the
Preset Switches)
(5) Connect the encoder and decoder, and transmit video and audio.
(5. Connecting the Encoder or Decoder)
(6) After transmission is complete, turn off the device and peripherals.
To Next Page
