Compact IP Codec User's Manual
12
Techno Mathematical Co., Ltd.
2140P
4.
Basic Settings
Configure the settings of this device from the application running under Windows.
Download the application software from the same download site where you
downloaded this User's Manual.
Starting Up the Application Software
To install the application software, execute the RemoteCtrl_nn.msi (nn: version
number) file you downloaded. After installation is complete, there will be two
icons on the PC desktop: ENCODER and DECODER.
Turn on the device.
Use LAN cable to connect the setup PC and the device remote connection port.
A network hub (with at least three ports) and three LAN cables can be used to
configure encoder and decoder settings simultaneously.
Set the PC IP address to match the remote connection IP address of the device.
The initial default settings of the IP addresses for device remote connection are
192.168.199.3 for the encoder and 192.168.199.4 for the decoder, so set the IP
address of the setup PC within the range of 192.168.199.1 to 255 (excluding
192.168.199.3 and 192.168.199.4).
• Open Control Panel.
• Click in the following sequence: Network and Internet → Network and Sharing Center
→ Change adapter settings.
• Right-click the icon of the network whose setting you want to change and then click
[Properties].
• Select Internet Protocol Version 4 (TCP/IPv4) and then click [Properties].
• Click Advanced Settings and then click [Add].
• Enter an IP address (such as: 192.168.199.1) and subnet mask (such as: 255.255.255.0)
and then click [Add].
Configuring the PC IP Address Setting
