TMC TM7006E User Manual

Compact IP Codec User's Manual
23
Techno Mathematical Co., Ltd.
2140P
Figure 5-1 Encoder – Connect Setting
■ Start up ENCODER.
■ On the Connect Setting tab, select the
location in the [Password Management]
list where you want to add the password,
and then click [Edit].
Figure 5-2 Encoder – Add Password
■ Enter the password you want to set and
then click [OK].
*Remarks can be left blank.
(3) Decoder Settings
Connect the setup PC to the decoder remote port and configure the settings below.
Table 5-2 Normal Connection – Decoder Settings
Setting Description Initial Default
UserName Sets the user name. (Up to eight single-byte
characters)
When connected, the user name will be shown in
the encoder status.
user
Password Sets a connection password (the same password
registered on the encoder, up to eight single-byte
characters).
password
Select
