Toa VX-2000 Series - Page 256

Chapter 9: CONNECTIONS
6. CONNECTION CABLE PIN ASSIGNMENT
9-34
To VX-200SO CTRL OUT
RJ45 connector
Pin No.
1
2
5
4
3
6
7
8
RJ45 connector
Pin No.
1
2
5
4
3
6
7
8
RJ45 connector
Pin No.
1
2
5
4
3
6
7
8
RJ45 connector
Pin No.
1
2
5
4
3
6
7
8
1 – 4
5 – 8
9 – 12
13 – 16
CTRL OUT 1
COM 1
VX-200SO Control Output
Electrical characteristics
Withstand voltage: 30 V DC
Contact current: Under 1 A
Circuit: No-voltage make contact
Control Output
CTRL OUT 2
COM 2
CTRL OUT 3
COM 3
CTRL OUT 4
COM 4
CTRL OUT 5
COM 5
CTRL OUT 6
COM 6
CTRL OUT 7
COM 7
CTRL OUT 8
COM 8
CTRL OUT 9
COM 9
CTRL OUT 10
COM 10
CTRL OUT 11
COM 11
CTRL OUT 12
COM 12
CTRL OUT 13
COM 13
CTRL OUT 14
COM 14
CTRL OUT 15
COM 15
CTRL OUT 16
COM 16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
[VX-200SO connection example]
