32
● External output data length (Default: 8 bit)
Select the communication data length (7bit / 8bit))
* Select 8bit when using the included USB cable (#584).
* Select 7bit when outputting data to EPP16M2 Tohnichi printer.
Use key to select and MEM key to confirm and proceed to the next.
(Press MD key to proceed without saving. Press C key to return to RUN measuring mode.)
● External output parity setting (Default: EVEN)
Set the parity for external output (EVEN / ODD / NONE)
* When connected to EPP16M2 Tohnichi printer, select NONE.
* When connected to PC, set the same parity as the PC setting.
Use key to select and MEM key to confirm and proceed to the next.
(Press MD key to proceed without saving. Press C key to return to RUN measuring mode.)
