Tohnichi CTA2-G - Page 40

39
*If there is no 2
nd
angle tightening stage, set the value to 000, then it proceeds to number of
spindles setting.
● 2
nd
angle upper limit setting (Default: 0)
Set the 2
nd
tightening angle upper limit.
Use key to select the digit, and key to change the value. Press MEM key to confirm
and proceed to the next.
(Press MD to proceed without saving. Press C key to return to RUN measuring mode).
● 3
rd
angle setting (Default: 0)
Set the 3
rd
tightening angle.
Use key to select the digit, and key to change the value. Press MEM key to confirm
and proceed to the next.
(Press MD to proceed without saving. Press C key to return to RUN measuring mode).
*If there is not 3
rd
angle tightening stage, set the value to “000”, then it proceeds to number of
spindle setting.
● 3
rd
angle upper limit setting (Default: 0)
Set the 3
rd
angle upper limit.
Use key to select the digit, and key to change the value. Press MEM key to confirm
and proceed to the next.
(Press MD to proceed without saving. Press C key to return to RUN measuring mode).
● Number of spindle setting (Default: 01)
Set the number of spindles.
