9
Press the RUN/HOLD switch.
The message "Measuring" is displayed on the LCD, and measurement by the reference
luminance colorimeter starts. After measurement end, the following screen is displayed.
・ In the case that each of the various communication settings is not correct,
data communication cannot be performed. Check whether setting has
been performed properly according to the Error display.
Meaning of Error Displays
☞
「1.5 Error Display」
10
Switch dip switch 8 of the BM-7AC to be corrected to the WRITE side to write data.
11
Place the BM-7AC to be corrected at the location where the reference luminance
colorimeter is placed, then press the [ENTER] button to display the following screen.
Select "Measure Factor" and press the [ENTER] button.
12
Specify a number to write the data for the BM-7AC to be corrected. Select the number
where the data for the reference luminance colorimeter is written, then press the
RUN/HOLD switch to start measurement.
・ If the data of the reference luminance colorimeter is not written in "REF",
measurement is not performed.
13
The message "Measuring" is displayed on the LCD, and the BM-7AC to be corrected
begins measurement. After finish of measurement, the following screen will be displayed
for about 3 seconds.
To Next Page
