āˆ’ 40 āˆ’
R-CL300-0-1204-02
3-5 PCB Names
PRINTER PCB
CPU PCB
CCD PCB
I/O PCB
I/O PCB (without LAN)
MEMORY PCB
POWER SW PCB
