Topcon CV-5000 - Page 25

− 23 −
YES
NO
!
YES
YES
YES
NO
NO
NO
#
1
The instrument is not activated.
Is the relay connector of
the instrument cable set?
Set the relay connector.
Is the MAIN connector
of the instrument set?
Is there +24V between
+24V and GND in the
MAIN PCB?
Is the LED of the
MAIN PCB turned on?
Fix the MAIN connector to
the MAIN PCB.
Replace the MAIN PCB.
R-CV5000-0-0704-01
