− 24 −
YES
NO
!
YES
YES
NO
NO
The continuity of
the CV CS cable has already
been checked.
Replace the CV CS cable.
Are the legs of
the MAIN PCB and IC short-circuited
with metal parts?
The +24V voltage
from the PS UNIT has already
been checked.
Replace the MAIN PCB.
Prevent short circuit.
Check the PS UNIT.
R-CV5000-0-0704-01
