18
Preliminaries
4.
Inst
alling and Removing the Battery
Install a fully-charged battery (see
"18. Ch
arging the Battery").
1
2
3
Procedure
•
Always turn off the power befor
e removing
the battery from the
instrument. If the battery is removed when the power is still on,
stored data may be lost.
Important:
DL502-503.bo
ok
18
ページ
２０１０年
４月５日 月曜日
午前９時４７分
18
20
