57
Other Procedures
Waving: For measurement using Wave-and-Read
function
Repeat: The instrument repeats fine measurements
until the operator presses or .
Page 2
Tracking:
The instrument repeats coarse measurements
until the operator presses or .
16.2 Fractional/Decimal Representation of Height
Units
You can set the fractional/decimal display format for
displaying height values.
The following options are available when using "m" as the unit:
* 0.0001m: Up to 4 decimals (when measuring mode is
"single", "repeat", "average" or "Waving")/Up to
3 decimals (when measuring mode is
"tracking")
0.001m:
Up to 3 decimals ("single", "repeat", "average
"
or
"
Waving
")/Up to 2 decimals ("tracking").
The following options are available when using "ft" as the unit:
* 0.001ft: Up to 3 decimals (when measuring mode is
"single", "repeat" or "average")/Up to 2
decimals (when measuring mode is "tracking").
0.01ft:
Up to 2 decimals ("single", "repeat" or "average")/
Up to 1 decimal ("tracking").
Only the following option is available when using
"inch" as
the unit:
• When is pressed in Set-out mode, the Measurement
conditions setting screen can be displayed.
Note:
DL502-503.book 57 ページ ２０１０年４月５日 月曜日 午前９時４７分
