Surveying
39
10. Measuring Elevation
From a known elevation (point A), you can measure the elevation (HA
+
Δ
H) of a specified ground point (point B).
The procedure below is for taking single measurements
when "Manual" is selected in the Record conditions menu.
1 Set up the instrument between points
A and B.
2 In menu mode, select "Elev.".
3 Input the backsight elevation.
4 Measure the backsight.
• When moving the instrument to a new position (step 9 below),
press "Yes" to save the Turning Point before switching off the
power.
Important:
