4. ON-DEMAND REMOTE CONTROL FUNCTIONS
3. Set measurement settings for the total station
and select prism type.
"6. SETTINGS FOR THE TOTAL
STATION"
Prism selection: Operator’s Manual for
your total station, "EDM Settings"
4. Check that total station Bluetooth settings are
made and the instrument is ready for
communication.
"6. SETTINGS FOR THE TOTAL
STATION"
After completing the total station preparations
above, the next step is to prepare the Remote
Controller.
5. Press the POWER button to switch ON
the Remote Controller. ● POWER is Lit.
6. Fix the pole vertically over the measurement
point and point the laser projection port of the
Remote Controller roughly in the direction of
the total station.
If the distance between the total station and the
Remote Controller is over 100m (normal
atmospheric conditions)/150m (good
atmospheric conditions), set to Far Mode by
pressing the FAR button
( ● FAR is Lit).
For atmospheric conditions, see
"7.3.2 Setting Distance Mode"
7. When
SEARCH button is pressed or
turning operationthe is instructed from the data
collector, the total station starts turning
operation.
8. Send an instruction from the data collector to
perform measurement.
• When returned laser signal is weak (object with low reflection factor):
Even if the laser beam received by the total station has been reflected off an unrelated object, or
sunlight has entered the beam detector, the total station still attempts to complete the stages of
Turning operation as far as Auto Pointing. When the total station judges that the laser beam has not
travelled directly from the Remote Controller to the beam detector, this position reading taken in
error is nullified and the total station automatically continues Turning operation at the next position.
