Topcon RC-5A - Prism System Configuration; Pin Pole System Setup

16
5. SYSTEM CONFIGURATION
For use with other prism types, contact your local dealer.
●
Pin Pole Type
5.2 System Configuration of the Remote Controller
RC-Handle for RC-5A
Adapter
Pin pole for
Pin
Pin pole point
AP66
SB184
360° Prism
360° Sliding Prism
RC-5RH
h1
ATP1
PP2
ATP1SII
Pin pole point
AP66
5 cm
5 cm
5 cm
h2
Pin Pole
example
pole
ATP1SII
Pin
pole
Pin
pole
Protector
RP3
Protector
RP3
