11. SPECIFICATIONS
RC-Handle ( RC-5RH )
Sensitivity of levels 35’/2mm
Size (when attached to RC-5A)
80.5 (W) X 126.5 (D) X 242 (H) mm
Weight (when attached to RC-5A, with BDC46C)
About 510g
360° Prism (ATP1)
Measuring range (Using total station, angles of elevation and inclination both less than
15°)
EDM 1.3 to 1000m
*9
Auto Tracking/Auto Pointing 2 to 600m
*9
Prism constant 7mm
3D positioning accuracy (standard deviation)
3mm (Angles of elevation and inclination both less than 20°)
Prism height 37mm (from mounting face (flange face) when attached to RC-5A)
Operating temperature -20 to 50°C
Storage temperature range -30 to 70°C
Size 70 (W) X 104 (H) mm (with cap)
Weight 265g (with cap)
*9: No haze, visibility over 20 km, slightly overcast (less than 30000 lx), no scintillation.
360° Sliding Prism (ATP1SII)
Measuring range (Using total station, angles of elevation and inclination both less than
15°)
EDM 1.3 to 1000m
*1
Auto Tracking/Auto Pointing 2 to 600m
*9
Prism constant 7mm
3D positioning accuracy (standard deviation)
3mm (Angles of elevation and inclination both less than 20°)
Prism height 50mm (When attached to Pin Pole for ATP1SII PP2, from bottom of
pin pole)
100mm (When attached to Pin Pole for ATP1SII PP2 and prism foot
AP66, from tip of prism foot)
Prism slide range 50mm to 350mm (When attached to Pin Pole for ATP1SII PP2,
graduations at 50mm intervals)
Operating temperature -20 to 50°C
Storage temperature range -25 to 70°C
Size
360° Sliding Prism ATP1SII 65 (W) X 77.5 (H) mm
Pin Pole for ATP1SII PP2 Ø6mm X 432mm (including connecting screw section and pole ends)
Weight
360° Sliding Prism ATP1SII 160g
Pin Pole for ATP1SII PP2 110g
ATP1SII, PP2 and AP66 290g
