Topcon RL-VH3 Series User Manual

13
Magnetic Scanning Target
Magnet
Detector
Datum line
Index
Index
Alignment target
Index
The blue target is for RL-
VH3G and the red target is
for RL-VH3A/B.
L
O
C
K
U
N
L
O
C
K
Wall mount model-2C
Wall mount hole
Mount position
control line
Clamp lever
Traveling stage
Wall mount hole
Wall mount model-1C
Clamp lever
Laser mounting screw
Elevation clamp
knob
