67
Specifications
Accuracy
Upright
instrument
Horizontal rotation ±10"
Vertical laser beam (Upward) ±15"
Vertical laser beam (Downward) ±0.5mm/1m
Laydown
instrument
Vertical rotation ±15"
Horizontal laser beam (Forward) ±10"
Horizontal laser beam (Backward) ±0.5mm/1m
Auto-leveling range :
±5°
Measuring range
Range of visible laser beam * Note1)
Horizontal, Vertical (When scanning) Radius approx. 50m (164ft)
Laser beam spot (Upward) Radius approx. 50m (164ft)
Laser beam spot (Downward) Radius approx. 5m (16.4ft)
Note1)The distance of visible laser beams are not constant due to the
brightness of the surroundings.
Using with LS-70A/70B
(RL-VH3A/B Only)
: Diameter 2 to 500 m ( 6.6 to 1640.5ft)
Light source :
L.D (Visible laser)
Wave length :
633nm (RL-VH3A/B)
:
532nm (RL-VH3G)
