Digital program switch menu
ENABLE YES
NO
RESET
STATUS
14EN
HOUR RANGES
SETUP
PARAMETERS - accessible only with expert password (default 2426)
This can be used to set an opening mode for different hour
ranges every day
Allows you to set/view the switch parameters
: Is valid for sensors N.O. with test and N.C. with test and
allows you to manually enter the sensors not learned
in the learning phase
Safety door opening 1
Lateral safety 1
Antipanic
ON
OFF
Same as safety door opening 1
IB2 MODE
ENTRY ONLY
EXIT ONLY
AUTOMATIC
Same as IB1 MODE
IB1 MODE
DAY 1
FROM 1 TO 6 HOUR
RANGES
START TIME 00:00
END TIME 00:00
MODE CLOSED
ENTRY ONLY
EXIT ONLY
AUTOMATIC
PARTIAL
OPEN
*Important: verify that the last time slot
used terms to 23.59
DAY 2
DAY 3
DAY 4
DAY 5
DAY 6
DAY 7
SEE DAY 1
SEE DAY 1
SEE DAY 1
SEE DAY 1
SEE DAY 1
SEE DAY 1
COPY
YES
NO
SYSTEM INFO
Displays the system information
COUNTERS CYCLES
METERS TRAVELED
RADAR ENABLING
: can be used to copy the first timer entered
( day 1) in all the other days.
MAINTENANCE
see maintenance section
ERROR LIST
MODEL
SW DOOR
: displays the last 8 errors with date and time. See error table
Allows you to set/view the switch parameters
WINGS FREE ON
NEAR
USER PASSWORD
DATE/TIME
LAMP MODE
SA: only fire alarm or Emergency button
SAMT: only alarm, key, or power outage
FO: hour ranges
: Perform a reset
: if entered, requires the password for any functionality editing,
if set with 0000 is not required
HOUR RANGES
DIMMING
2 hour ranges
START TIME 00:00 on
END TIME 00:00 off
LCD CONTRAST
LCD RETRO
RUN
: allows you to perform a new learning cycle of the
parameters and sensors connected (in case of use
of monitored sensors)
Safety door opening 2
Lateral safety 2
Same as safety door opening 1
Same as safety door opening 1
Same as safety door opening 1
MOVEMENT
PARAMETERS
OPENING SPEED
CLOSING SPEED
OPENING
ACCELLERATION
CLOSING
ACCELERATION
OPENING BRAKING
CLOSING BRAKING
SPEED OF
APPROACH
IN OPENING
SPEED OF
APPROACH
IN CLOSING
: set maximum speed that can be reached
in opening
: set maximum speed that can be reached
in closing
: allows you to change the acceleration of the door
during opening. Variable from 1 to 12.
: allows you to change the acceleration of the door
during closing. Variable from 1 to 12.
: allows you to change the braking of the door
during opening.
Variable from 1 to 12.
: speed at the end of the braking ramp. Variable
From 1 to 5 cm/s.
: allows you to change the braking of the door
during closing.
Variable from 1 to 12.
: speed at the end of the braking ramp. Variable
From 1 to 5 cm/s.
NOTES: Opening and closing speed variable from 10 to 80
In some cases the speed setting may not be reached, depending on the
size of the opening, acceleration and braking settings and weight of the door
SW DATA
SW DS2
SW DATA
Motor.Temp
Diagnostic
: only interlocked doors
17
EN
DIAGNOSTIC
INPUTS
EXITS
ENCODER
: Displays all the internal and external radar inputs:
V.P. and lateral guards, key, emergency and fire
alarm/antipanic button
:Allows you to enable the following outputs :
electric locks
air blades and lamp.
:Also allows you to view the encoder position
: allows the use of "Wings free",
if the automation board is set up
for the "Wings free", function.
WINGS FREE
PHARMACY
