REQUIRED TOOLS
REQUIRED TOOLS
This procedure requires the following tools. Collect them before you begin.
l 3 in. (7.6 cm) wooden block, 2
l 6 in. Gear puller
l Flat-blade screwdriver
l Metric hex wrench set
l Open-ended wrenches:
l 13 mm
l 19 mm
l 25 mm
l Phillips screwdriver
l Safety eyewear
l Simple Green (or similar mild degreaser)
l Torque wrench
l WD-40® (or similar water displacement oil)
BEFORE YOU BEGIN
l
M+Upgrade Required You must use servo motors with the BT30 spindle. If you haven't yet done so, install
the 1100M+ Servo Upgrade Kit (PN39274).
l
Power Drawbar Required You must have a power drawbar to use with the BT30 spindle. Depending on
what's installed on your machine, do one of the following:
l
TTSPower Drawbar Installed Use the TTS to BT30 Power Drawbar Conversion Kit (PN 50474) to
upgrade your existing power drawbar.
l
No Power Drawbar Installed Install the 1100MX/770MX Power Drawbar Kit (PN 50433).
l
Keep All Hardware To install the BT30 spindle, you'll reuse many items currently used on the machine.
Keep all hardware unless you're specifically instructed to discard it. If you don't, there's a risk that you won't
have the hardware you need to complete the installation.
l
PathPilot v2.4.2 or Later Required Only PathPilot v2.4.2 and later has settings required to use an MX
mill configuration. For information, go to "Update PathPilot" (page4).
Page 3
©Tormach® 2021
Specifications subject to change without notice.
tormach.com
TD10705: Installation Guide: BT30 Spindle Upgrade Kit for 1100M+ (0521A)
