Tormach BT30 User Manual

SPINDLE HEAD PARTS LIST
Spindle Head Parts List
ID Description Quantity
1 1100 Head Casting (PN30323) 1
2 1100 Spindle Motor Mount (PN 30324) 1
3 Spindle Pulley
1
1
4 Power Drawbar Flange
1
1
5 Bearing Nut, M25 × 1.5, Set Screw (Angled)
1
1
6 Drawbar, R8 (7/16-20), 305 mm (PN38793) 1
7 Power Drawbar Alignment Bushing (PN 31330) 1
8 1100 Spindle Motor Pivot Plate (PN30341) 1
9 Spindle Motor, 1100 (PN30346) 1
10 Motor Pulley Spacer, 1100 (PN30347) 1
11 Key, 8 mm × 7 mm - 40 mm (PN 30348) 1
12 Pivot Bushing (PN 30350) 1
13 Pulley Washer (PN30351) 1
14 Tensioning Handle Detent Pin (PN 30336) 1
15 Spring, 1 × 4.8 × 20 (PN30338) 1
16 Pivot Plate Pin (PN 30340) 1
17 Spindle Motor Handle (PN30339) 1
18 Screw, Cone Point Set, M5 x 0.8 - 8 (PN30337) 1
19 Washer, Flat, M10 (PN30325) 4
20 1100 Motor Pulley (PN37733) 1
21 Pivot Plate Clamp Bolt (PN30342) 1
22 Pivot Plate Clamp Handle (PN30345) 1
23 Clamp Handle Detent Pin (PN30343) 1
24 Spring, 1 × 4.8 × 20 (PN 30344) 1
25 Pin, 4 mm - 16 mm (PN30395) 1
26 Washer, Split Lock, M12 (PN 30321) 7
27 Washer, Flat, M12 (PN30322) 1
28 Pin, Taper, 8 mm - 40 mm (PN30320) 2
Page 36
©Tormach® 2021
Specifications subject to change without notice.
tormach.com
TD10705: Installation Guide: BT30 Spindle Upgrade Kit for 1100M+ (0521A)
