INSTALL AN UPDATE FILE FROM A USB DRIVE
5. From the dialog box, select OK.
The update file is installed on the PathPilot controller.
6. Follow the on-screen instructions to restart the PathPilot controller.
Install an Update File from a USB Drive
1. From the PathPilot support center, download the most recent PathPilot update file.
2. Transfer the PathPilot update file to a USB drive.
3. Put the USBdrive into the PathPilot controller.
4. Confirm that the PathPilot controller is powered on and out of Reset mode.
5. From the Status tab, select Update.
Figure 4: Update button on the Status tab.
6. From the Software Update dialog box, select Browse.
Figure 5: Software Update dialog box.
Page 5
©Tormach® 2021
Specifications subject to change without notice.
tormach.com
TD10705: Installation Guide: BT30 Spindle Upgrade Kit for 1100M+ (0521A)
