Complete the following steps in the order listed:
Remove the R8 Spindle 7
Install the BT30 Encoder 17
Install the BT30 Spindle and Align the Encoder 22
Install the VFD 29
Verify the Installation 32
Remove the R8 Spindle
Tip! For more information while removing original components of the machine, it may help to
refer to the "Spindle Head Exploded View" (page35).
Prepare the Machine
1. Remove any tooling, fixtures, workpieces, or parts from the machine.
2. Jog the spindle nose until it's approximately 6 in. (15.2 cm) above the machine table.
3. Power off the machine and the PathPilot controller.
a. Push in the machine's red Emergency Stop button, which removes power to motion control.
b. From the PathPilot interface, select Exit.
c. Turn the Main Disconnect switch to OFF on the side of the electrical cabinet.
4. Disconnect any pneumatic air lines on the machine, and verify that the lines are empty.
5. Open the spindle cover and lock it in the upposition.
