Tormach BT30 User Manual

SPINDLE CARTRIDGE PARTS LIST
Spindle Cartridge Parts List
ID Description Quantity
1 Magnetic Encoder, Spindle Ring (PN 38298) 1
2 Spindle Pulley, 1100MX (PN 39576) 1
3 Flange, BT30 Power Drawbar (PN 39577) 1
4 Key, Straight, 6 mm × 6 mm - 64 mm (PN 39579) 1
5 Disc Spring Guide, MX BT30 Spindle (PN 39597) 1
6 Disc Spring Compression Nut, MX BT30 Spindle (PN 39598) 1
7 Disc Spring, 40 mm × 20.4 mm × 2.0 mm × 3.10 mm (PN 39689) 16
8 Nut, Jam, M12 × 1.75 (PN39602) 1
9 Drawbar, BT30 Spindle (PN 39574) 1
10 Clamping Unit, BT30 (PN 39690) 1
11 Key, Straight, 4 mm × 4 mm - 12 mm (PN 39601) 1
12 O-Ring, 9 mm × 12 mm × 1.5 mm, Buna-N (PN 39584) 3
13 Nut, Bearing, M25 × 1.5 (PN 39589) 1
14 Drawbar Core Assembly, MX BT30 Spindle (PN 39599) —
Page 40
©Tormach® 2021
Specifications subject to change without notice.
tormach.com
TD10705: Installation Guide: BT30 Spindle Upgrade Kit for 1100M+ (0521A)
