Tormach BT30 User Manual

SPINDLE HEAD PARTS LIST
ID Description Quantity
29 Wear Strip, Spindle Door (PN 38451) 2
30 Screw, M5 × 0.8 -14 (PN37901) 6
31 Spindle Lock Base (PN 38716) 1
32 1100M Spindle Lock Bar (PN38717) 1
33 Washer, M6, Nylon (PN 38714) 2
34 Screw, M8 × 1.25 - 10 mm (PN 31682) 1
35 Spring, 6 mm × 20 mm (PN 31559) 1
36 Ball, 6 mm, Steel (PN38225) 1
37 Washer, Split Lock, M10 (PN 31684) 11
38 Screw, Socket Head Cap, M10 × 1.5 - 30 (PN31894) 10
39 Screw, Socket Head Cap, M8 × 1.25 - 20 (PN31895) 1
40 Washer, Flat, M12 (PN 32473) 7
41 Screw, Socket Head Cap, M12 × 1.75 - 45 (PN30349) 1
42 Washer, Flat, M10 (PN 30919) 6
43 Screw, Socket Head Cap, M12 × 1.75 - 50 (PN32476) 6
44 Screw, Socket Head Cap, M6 × 1 - 45 (PN 38715) 1
45 Screw, Socket Head Cap, M6 × 1 - 20 (PN 30832) 2
46 Key, 6 mm × 6 mm - 55 mm
1
1
47 Spindle Pulley Spacer
1
1
48 Tormach Tooling System (TTS) Adapter Collet: R8 (PN 50568) 1
49 Machine Screw, Socket, M8 × 1.25 - 30 (PN 30544) 6
50 Spindle Housing, 80 mm (PN 37701) 1
53 Spindle Shaft, R8 (PN37702) 1
54 Spindle Nose Closure, 80 mm (PN37703) 1
55 1100 Bearing Spacing Sleeve (PN 37704) 1
56 1100 Upper Bearing Shield (PN37705) 1
57 Nut, Bearing, M35 × 1.5, Set Screw (PN 37567) 1
58 Pin, 3.5 mm × 9 mm (PN 38353) 1
59 Power Drawbar Spring Washer (PN 31319) 8
60 Screw, Socket Head Cap, M4 × 0.7 - 16 (PN37751) 8
Page 37
©Tormach® 2021
Specifications subject to change without notice.
tormach.com
TD10705: Installation Guide: BT30 Spindle Upgrade Kit for 1100M+ (0521A)
