1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measures for averting danger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these sections can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type: Electro-mechanical sliding door drive with DC motor
Control system: Control unit 2101
MCU42-COU-A
Control unit 2101
MCU42-COU-B
Mains connection: 230 / 115 V AC 230 V AC
Nominal voltage max.: 0,95/1,9 A 1,9 A
Nominal frequency: 50 – 60 Hz
Power consumption: 190 W
Motor: 24 V DC, 2,7 A
Sensor supply: 24 V DC, 0,75 A
Protective class, drive: IP 20
Ambient temperature: –20 °C to +50 °C
Noise emission level: typically 55 db (A)
