8 Instructions for Use Win Drive 2201 T-1165 e
– Continuedoperationofthesystembymeansofabatteryunitu for a specific time with the doors open-
ing before the battery switches off. The door remains locked in operating mode OFF.
– Unlockingandopeningof thedoorfromoutsidebymeansofakeyswitchandthebatteryunitu.
3.3 Operating Modes
By using the TORMAX user interface u it is possible to operate the automatic door system in 6 operating
modes and with status displays or to use a simple operating mode switch u to operate the door in 3 op-
erating modes.
Operating Mode OFF
Theinternalandexternalsensorsaredisregarded.Thedoorismaintainedintheclosedpositioneitherby
the motor or the holding magnet uand/orlockedbytheelectro-mechanicallocku. Access is only pos-
sible using the key switch u.
< The door can still be used for 10 seconds after selecting operating mode OFF. The transition is signalled
ontheuserinterfacebytheashingdisplayofoperatingmodeOFF.
Operating Mode AUTO
The operating mode AUTO is normally used during the day. The door opens automatically to its full open-
ingwidthtobothsidesbymeansoftheinternalandexternalsensors.
Operating Mode AUTORED
Operating mode AUTORED is normally used for daytime operations. The door opens automatically with
areducedopeningwidthtobothsidesbymeansoftheinternalandexternalsensors.
< If required, the opening width can be altered by the installer.
Operating Mode EXIT
Operating mode EXIT is normally used for the period before the shop or office closes. The door will only
open automatically when activated by the internal sensor.
Whenthedooropenstheexternalsensorisalsomonitoredforsafetyreasons.
The opening width is determined by previously selecting operating mode AUTO or AUTORED. The door can
be automatically blocked using the holding magnet u.
Operating Mode OPEN
The door opens and remains open. The opening width is determined by the prior selection of operating
mode AUTO or AUTORED.
Operating Mode Manual Operation
The door leaves can be freely moved. This operating mode can be used for cleaning the door leaves and
theoorguideorfortemporarilyshuttingdownthedoor.Thesystemisresetafterleavingthisoperating
mode.
