Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e 13
Systems with an Electrical Door Opener
The electric door opener unlocks on every valid opening impulse. The electrical door opener must be
manually activated with the door handle before it is possible to open the door with the “Push- and-Go”
system. In this operating mode the electrical door opener can also be permanently unlocked depending
on the setting programmed at the time of commissioning.
Operating Mode AUTOMATIC 2
Corresponds to operating mode AUTOMATIC 1 but a different motional sequence can be set during
commissioning (e.g. a slower opening movement, different open positions and a longer hold-open time).
Operating Mode EXIT
Operating mode EXIT is normally used for the period before the shop or office closes. The door will
only open automatically when activated by the internal sensor. When the door opens the external sen-
sor is also monitored for safety reasons. The open position is determined by the preceding selection
of the operating mode AUTOMATIC 1 or AUTOMATIC 2. The door can be locked automatically by the
electric door opener. The electric door opener can be permanently unlocked in this operating mode in
case of need.
Operating Mode OPEN
The door opens and remains open. The open position is determined by the preceding selection of the
operating mode AUTOMATIC 1 or AUTOMATIC 2. The door opens again on receiving the next open
impulse or when changing the operating mode to OFF and back again to OPEN.
Operating Mode Manual Operation
The door leaf can be freely moved. This operating mode can be used for cleaning the door leaf or for
temporarily shutting down the door. The system is reset after leaving this operating mode.
In this operating mode the electric door opener can also be permanently unlocked depending on the
setting programmed at the time of commissioning.
