Tormax iMotion 1301.FIRE User Manual

Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e 3
1 General Information
1.1 Target Groups
• Operator of the automatic swing door. The operator is the person responsible for the operation and
maintenance of the system.
• Persons instructed by the operator to carry out certain duties, for example the servicing and main-
tenance of the automatic swing door.
1.2 Storage and Forwarding of the Manual
• Store the instructions for use in the vicinity of the automatic door system.
• If the manual has become illegible due to constant usage, reorder the instructions.
For download and print out see also: www.tormax.com
• When the door system is transferred or resaled to a third party, pass the following documents to
the new owner:
– This instructions for use
– Documentation concerning modification and repair work
– Proof of the regular examinations  System test book T-1543
1.3 Area of Application
Product name, door system: Automatic swing door and hold-open system for fire doors
Product name, door drive: iMotion 1301.FIRE Swing Door Drive
iMotion 1401.FIRE Swing Door Drive
The door drives are defined in more detail by a 4-figure number:
DIBT (German Building Technology Institute) technical approval: approval number Z-6.510-2569:
see document T-1570, download www.tormax.com
The identification plate with the serial number is
placed in the control box (1401) or on the drive
itself under the casing (1301, 1301.S).
Contact
Manufactured
Initial
Commissioning
System No.
Sliding Door
System
TORMAX …………… .HERM
WT-299 e 3.18
DIN 18650-1:2010
N
e
x
t
S
e
r
v
i
c
e
2019
000/000/00
MM.YYYY
DD.MM.YYYY
Max Muster AG
Hauptstrasse 43 – 8049 Zürich
SERVICE: 043 827 33 55
Continuous numbering
Drive for swing door system
Increasing power
1 3 0 1
.FIRE = Drive for fire doors
Door system identification plate (example): located
on the side panel of the drive.

Tormax iMotion 1301.FIRE Specifications

General

Brand	Tormax
Model	iMotion 1301.FIRE
Category	Door Opening System
Language	English
