4 Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e
1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measures for averting danger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these sections can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type Electromechanical swing door drive with AC permanent magnet
synchronous motor
Control system iMotion MCU32
Mains connection 1 x 230 V AC, 10 – 16 A / 1 x 115 V AC, 15 – 20 A, 50 – 60 Hz
Power consumption iMotion 1301.FIRE 12 … 330 W
iMotion 1401.FIRE 6 … 250 W
Sensor supply 24 V DC + 0,5/ –1,5 V, max. 36 W / 1,5 A,
Fire protection module 24 VDC max. 7,2 W / 0,3 A
Protective class, drive iMotion 1301.FIRE IP 20
iMotion 1401.FIRE IP 68
Ambient temperature –20 °C to +50 °C
Noise emission level < 70 db (A)
Electromagnetic IEC 61000-6-2, IEC 61000-6-3
compatibility (EMV)
Service life Tested to 1’000’000 cycles
<
