18
MAINTENANCE
Vacuum and Water Recovery System
NOTE: A dirty or clogged filter will greatly reduce
suction and the ability of the machine to recover
water.
Inspect the vacuum filter after each use as follows:
1. Disconnect hose.
2. Turn the two cam-shaped thumb locks.
3. Remove filter assembly.
4. Rinse the filter screen with clean water.
5. Drain and flush tank with clean water.
6. Leave filter assembly out of tank to allow system to dry when
not in use.
A liquid shutoff is built into the filter system to prevent overfilling
tank. Do not disassemble or modify the white plastic float, or
vacuum motor damage may result.
Solution and Recovery (Vacuum) Tanks
Draining Recovery (Vacuum) Tank:
1. Lift drain hose and remove from hook.
2. Insert end of hose into large pail or drain area.
3. Push ball to the side and drain. (Do not remove ball from
hose.)
4. For more extensive cleaning of tank, loosen two thumb nuts
and remove cover. Flush out tank with clean water as
necessary.
