19
MAINTENANCE
Draining Solution Tank:
1. Locate drain hose at front of unit and position over
acceptable floor drain or container.
2.Turn valve handle to open drain valve.
3.Return valve handle to closed position. Tuck drain
hose back on machine.
Flush and clean tanks after each use and allow to air
dry to eliminate odors and corrosion of vacuum motor.
Vacuum Motor
To service vacuum motor which is located above re-
covery tank:
1. Disconnect vacuum hose clamp.
2. Remove four screws.
3. Disconnect wires and remove cover.
4. Remove vacuum motor to service.
Wheels
Machines are equipped with either pneumatic or
optional foam-filled tires. Be sure to keep pneumatic
tires at 48-50 psi to ensure proper machine
performance. No service is required for foam-filled
tires.
